Technical Specifications

Servo Based 6 Colour Printing Unit with All UV Dryer and Hot Air Dryer

Automatic Plate Registration System

Chiller Drum System

Full Touch Screen Control System

Unwinding Unit:
  • -Max Roll ø1000mm
  • -3” Air Shaft (75mm)
  • -Electronic Web Guide (ULTRASONIC BASED SYSTEM)
  • -With Slicing Table and Paper Holder
  • -Auto Electronic Tension Controller (Powder Brake) with Load Cell Feedback (IMPORTED)
  • -Air Pneumatic Loading System For Easy Loading of Reels

6 Nos Ceramic Anilox Rollers (As Per Your Requirement)

3 Set Printing Cylinde (As Per Your Requirement)

Individual Motorized Anilox Roll System for Each Printing Unit

Printing Unit Adopt 360° to Regulate Each Unit

No Need Pressure for every Job one-time set

Online Rotary Die Cutting Unit with Waste Matrix Rewinding

Rewinding Unit:
  • -Max Roll ø1000mm
  • -3” Air Shaft (75mm)
  • -Auto Tension Controller (Powder Clutch)

Speed - 100- 120 M/min (UV Dryer)

Max Print Width : 310 MM

Max Print Length : 450 MM

Extra Option:
VIDEO MONITOR:
TURN BAR FOR BACK SIDE PRINTING
DELAM-RELAM
SHEETER STACKER
SNOWBALL REWINDING
